DiGiGrid MGO - Optical Dual MADI to SoundGrid converter
DiGiGrid MGO - Optical Dual MADI to SoundGrid converter
In stock
Couldn't load pickup availability
DiGiGrid MGO – Optical MADI to SoundGrid Interface for LV1 & DAW Integration
The DiGiGrid MGO is a compact, high-performance optical MADI to SoundGrid interface, allowing you to connect MADI-enabled devices via optical output directly to your Waves SoundGrid network. Whether you’re mixing live with Waves LV1 Classic, recording multi-channel sessions in the studio, or capturing broadcast feeds, the MGO gives you pristine MADI connectivity with rock-solid performance.
With support for up to 128 channels at 48kHz (or 64 at 96kHz), the MGO is ideal for adding MADI I/O to your LV1 system or using it as a multi-channel DAW interface via the SoundGrid QRec driver — perfect for virtual soundchecks, recording, and playback.
Designed with portability and flexibility in mind, the MGO features Word Clock I/O, ultra-low latency, and full compatibility with SoundGrid DSP servers for real-time plugin processing.
Key Features:
• Optical MADI to SoundGrid converter – up to 128 channels at 48kHz / 64 at 96kHz
• Add MADI I/O to Waves eMotion LV1 Classic with seamless integration
• Record/playback via DAW using the SoundGrid QRec driver
• Ultra-low latency performance for live and studio use
• Word Clock input/output for sync stability
• Works with SoundGrid Studio ASIO/Core Audio drivers Mac and PC
• Compatible with SoundGrid DSP servers for plugin processing*
• Compact and robust – ideal for portable and rack-based systems
*SoundGrid DSP server required for real-time processing (sold separately)
In stock now at Nifty Audio, the UK’s exclusive DiGiGrid and Waves distributor. Fast next day delivery available.
Collapsible content
Technical Specs
Specs
- MADI Optical I/O (SFP Optics cartridges)
- Supported sample rates: 44.1, 48, 88.2, 96 kHz
- 112/128 channel I/O @ 48kHz
- 56/64 channel I/O @ 96kHz
- Support for 64chn and 56chn modes
- Support for double wire (48k frame) and single wire (96k frame) @ 96kHz
- Clock Synchronisation via (in fallback order): Word Clock input, MADI (port A), SoundGrid (SoE), Internal 1 SoundGrid port (RJ45)
- Reset switch
Package Contents
DiGiGrid MGO unit
Universal power adaptor with interchangeable plugs (UK, US, EU, AU) (100-240V)
Ethernet cable: Cat 5e (2 meters)
Registration card
Dimensions
Width: 10.6 cm / 4.17 inches
Height: 14.82 cm / 5.83 inches
Depth: 2.9 cm / 1.14 inches
Device Weight: 0.4 kg / 0.88 lbs
Case Studies
FAQ
What can the DiGiGrid MGO be used for?
MGO is used to integrate optical MADI systems into networked audio workflows. Common applications include:
- Live sound and touring systems
- Broadcast and OB truck workflows
- Multi-channel recording and virtual soundcheck
- Studio and hybrid production environments
It acts as a bridge between MADI hardware and SoundGrid processing systems.
What is the DiGiGrid MGO used for?
MGO is used to integrate optical MADI systems into networked audio workflows. Common applications include:
- Live sound and touring systems
- Broadcast and OB truck workflows
- Multi-channel recording and virtual soundcheck
- Studio and hybrid production environments
It acts as a bridge between MADI hardware and SoundGrid processing systems.
What latency does the DiGiGrid MGO provide?
When used in a SoundGrid system, the MGO operates at approximately 0.8 ms latency, depending on system configuration and buffer settings.
This makes it suitable for real-time live sound and broadcast workflows.
Can the MGO record to multiple computers?
Yes. The MGO can record to two computers simultaneously, allowing workflows such as:
- Primary recording + backup recording
- Virtual soundcheck + live capture
- Redundant DAW recording setups
Can the MGO also be used in studio setups?
Yes. The MGO is designed for both live and studio environments, including:
- Touring rigs with fibre MADI systems
- Broadcast infrastructure
- Studio recording and playback systems
- Hybrid DAW + live setups
If you wish to chat more about how to build a system around the DiGiGrid MGO - Optical Dual MADI to SoundGrid converter or integrate this into your current system, give us a call or email at:
