eMotion LV1 80 Channel Expansion

The Waves eMotion LV1 80-Channel Expansion is a software upgrade that expands the mixing capacity of your LV1 system, allowing engineers to handle larger productions and more complex routing setups without changing hardware.

With this expansion installed, a standard 64-channel LV1 system can be upgraded to 80 stereo channels, dramatically increasing the system’s mixing power. Because each LV1 channel can be configured as mono or stereo, the system can handle up to 160 inputs, making it suitable for large live productions, broadcast environments and complex multi-channel systems.

The expansion also increases the console’s bus structure from 44 to 52 buses, adding eight additional buses that can be configured as either audio groups or monitor aux sends. This allows engineers to create up to 16 audio groups or up to 24 monitor aux mixes, offering greater flexibility for front-of-house or monitor mixing workflows.

Delivered as a simple software license, the 80-Channel Expansion installs directly into existing LV1 systems—including modular LV1 setups or integrated consoles—making it an easy upgrade for engineers who need additional capacity for larger shows and productions.

Key Features

Expand LV1 from 64 to 80 stereo channels

Support up to 160 inputs when channels are configured as mono

Increase total bus count to 52 buses

8 additional buses configurable as audio groups or monitor auxes

Up to 16 audio groups or 24 monitor aux sends

Software upgrade—no additional hardware required

Compatible with LV1 systems running the latest software versions

Designed for Larger Productions

The 80-Channel Expansion is ideal for engineers working on productions that require higher channel counts, complex routing, or larger monitor mixes. From touring productions and broadcast environments to houses of worship and festival stages, the expansion provides the additional flexibility required for demanding live sound workflows.

When combined with the Waves SoundGrid ecosystem—including servers, stageboxes and plugin processing—the LV1 system can scale from compact setups to full-scale professional touring systems.
